Overview of ESCAM QF002 Wireless IP Camera CCTV 1/4 Inch CMOS 720P
Feel Safety and Secured
Features
No Blind Spot
CCTV ini dapat berputar 355 derajat dan gerakan atas bawah sebesar
120 derajat. Dengan jangkauan luas ini CCTV dapat menangkap semua sudut
ruangan Anda. |
Two Way Audio
Dapat berkomunikasi 2 arah melalui cctv dan smartphone. |
Support Day and Night
Memiliki sensor nightvision sehingga dapat digunakan untuk memonitor situasi diruangan gelap. |
Mail Detection, Email Alarm
CCTV ini dapat mengirim notifikasi ke smartphone Anda saat mendeteksi adanya pergerakan yang terekam dikamera. |
1MP HD 720P
Sensor kamera dapat merekam dengan kualitas HD hingga 1280 x 720
25FPS. Dengan resolusi ini Anda akan mendapatkan kualitas gambar yang
jelas dan jernih. |
TF Card up to 32GB
Dapat menggunakan memory Micro SD hingga kapasitas 32GB. Dengan ini Anda dapat menyimpang hasil rekaman cctv di memory ini. |
P2P
Dengan fitur P2P kamera ini dapat dihubungkan langsung dengan komputer Anda untuk monitoring secara langsung. |
Support Multi User Online
CCTV ini dapat diakses langsung oleh beberapa user dalam waktu yang bersamaan. |
Detail Specification
| Model: ESCAM QF002 | ||
| Features | System security | Account, password management |
| View by phone | Support HD pic IOS, Android mobile view (iOS 4.3?Android OS 2.3 above) | |
| Local Storage | support up to 32G TF card 24-hour loop recording. | |
| Monitor Advantage | Support PC computer monitoring, smartphone multi-pic view. | |
| UID Technology | UID scan technology applied, easy to operate, and highly confidential. | |
| Video coding | Multi stream: 720P/25fps+D1/25fps+CIF/25fps | |
| Bit Rate | CBR/VBR, output bit rate range?48?3072kbps | |
| Video | Compression Format | H.264 baseline profile |
| Frame rate | NTSC:30fps/PAL:25fps 720p | |
| Resolution | 720P(1280*720),D1(704*576), CIF(352*288) | |
| Picture Adjustment | Contrast, Brightness, Saturation are adjustable. | |
| Sensor | 1/4 720p Progressive CMOS sensor | |
| Minimum illumination | Color: 0. 1Lux, B/W: 0.01Lux | |
| SNR | >=39dB | |
| IR control | Auto | |
| Electronic shutter | 1/50s(1/60s -1/100, 000s | |
| CMOS | support AWB, AGC, BLC | |
| Lens/viewing angle | 3.6mm@F1 / 62.2 | |
| Night Vision | Night vision | Dual IR-CUT Filter auto switch, 11pcs 850nmΦ5mm LED,10m IR distance |
| Audio | Compression | G.711A |
| Input | 1 Channel Line in -48dB Microphone | |
| Output | 1 Channel Buit in speaker(8Ω1W) | |
| P/T | P/T | Pan:355°,Tilt:120° |
| Network | network interface | 10Base-T/100Base-TX Ethernet interface |
| Network Protocol | TCP/IP,HTTP,TCP,UDP,SMTP,FTP,DHCP,DNS,DDNS,NTP,UPnP,RTSP?P2P,etc. | |
| Online visitor | Support 4 online visitors simutaneoursly | |
| IP address | Dynamic IP and static IP address | |
| WIFI | WIFI 802.11 b/g/n | |
| Application environment | Indoor | |
| Rated Voltage | DC5±0.3V | |
| Temperature | -10~50 °C | |
| Power consumption | rated power 3.5 (IR opening )/maximum power 7W(P/T working ) | |
| Package size | 195x150x120mm (L×W×H) | |
| Weight | Gross Weight 530g Note: in kind prevail | |
| Accessories | Power adapter, user manual, mounting bracket, screws. | |
| Alarm | Motion Detection | Support motion detecting |
| Certificate | Certificate | CE RoHS |
| Only for reference | ||
Package Contents
Barang-Barang yang Anda dapatkan dalam kotak produk:- 1 x ESCAM QF002 Wireless IP Camera CCTV 1/4 Inch CMOS 720P
- 1 x Holder
- 1 x Plug Adaptor
- 1 x Cable Adaptor
- 2 x Set Screw
- 1 x Manual User
Photos of ESCAM QF002 Wireless IP Camera CCTV 1/4 Inch CMOS 720P
