Overview of ESCAM Keeper QF502 Wireless IP Camera CCTV 1/4 Inch CMOS 720P
Feel Safety and Secured
Features
|
QR Code Scan to Setup WiFi
Anda dapat dengan mudah mensetting WiFi dengan melakukan scan barcode dan setting akan dilakukan secara otomatis. |
|
Push Notification + Alarm Sound Alert
Dapat mengirim notifikasi ke smartphone Anda saat cctv ini mendeteksi pergerakan yang mencurigakan. |
|
Mobile Surveiliance
Anda dapat memonitor cctv melalui smartphone dan tablet Anda dimana saja dan kapanpun dengan koneksi internet. |
|
TF Card up to 32GB
Dapat menggunakan memory Micro SD hingga kapasitas 32GB. Dengan ini Anda dapat menyimpang hasil rekaman cctv di memory ini. |
|
Powerful Hisilicon Chipset
Menggunakan chipset Hisilicon generasi terbaru sehingga kamera ini dapat menghasilkan kualitas gambar yang sangat baik. |
|
Support Day and Night
Memiliki sensor nightvision sehingga dapat digunakan untuk memonitor situasi diruangan gelap. |
Detail Specification
| Specification | Type | Parameters |
| System | System security | Account, password authority management |
| DDNS | No need DDNS, support dynamic IP | |
| Mobile view | HD mobile view, dedicated software for Iphone, Android(IOS4.3 / Android OS 2.3 above) | |
| Local memory | Support up to 32G TF Card, loop recording | |
| P2P | Plug & Play technology applied. 99% penetration rate. | |
| Only three steps to view image. | ||
| Server cluster | Global PnP smart server cluster applied, high stability | |
| UID Technology | UID scan technology applied, easy to operate, and highly confidential. | |
| Video | Compression Format | H.264 , 1.0 megapixel |
| Frame rate | 1~30fps | |
| Resolution | 720P(1280 x 720) / VGA (c640 × 480) / QVGA (320 × 240) | |
| Image sensor | 1/4 CMOS | |
| Minimum Illumination | 2.5Lux ( color mode), 0.3Lux (B/W mode) | |
| SNR | ≥39dB | |
| Electronic shutter | 1/50s (1/60s)-1/100, 000s | |
| CMOS | support AWB, AGC, BLC | |
| Lens/Viewing Angle | 2.8mm @F1.4 / 56.14? | |
| Nightvision | IR-CUT | Dual IR-CUT Filter |
| Effect | 11pcs 850nmΦ5mm IR LED, IR Distance: 10m | |
| Two way Audio | Encode formats | AMR/32kbps |
| Input | 1 Channel Line in -48dB Microphone | |
| Output | built-in speaker(8Ω1W) | |
| PIR | PIR | Built in |
| Network | Socket | RJ-45 10/100Mb self-adaptable Ethernet slot |
| Network Protocol | TCP/IP, HTTP, TCP, UDP, SMTP, FTP, DHCP, DNS, DDNS, NTP, UPnP, P2P | |
| WIFI | WIFI 802.11 b/g/n | |
| IP address | dynamic IP | |
| visitors | Support 4 online visitors viewing simutaneously | |
| Alarm | Motion Detection | Support motion detection/one channel input trigger |
| Alarm detection | External trigger input action: connected / disconnected | |
| External trigger input action: closed / disconnected | ||
| Alarm Action | snapshot and email | |
| Linkage alarm | support up to 64 wireless alarm sensors, support one key arming and disarming. | |
| System | system configuration | Win2000 / XP, Vista, Win7, iPhone ios4.3, Andorid 2.3 above |
Other |
Power Comsumption | DC5±0.3V |
| Temperature | -10~50 °C | |
| Humidity | 95%RH | |
| Product Weight | 100g | |
| Gross Weight | 300g | |
| Product size | 100 x 65 x 40mm (L x W x H) | |
| Package size | 120 x 120 x 95mm (L x W x H) |
Photos of ESCAM Keeper QF502 Wireless IP Camera CCTV 1/4 Inch CMOS 720P
